General information: | |
---|---|
With video: | Yes |
Type: | single-family |
Installation technique: | Multi-wire system |
Number of wires: | 4+2 |
Type of transmission: | wired/WiFi |
Nominal voltage: | 15V |
Current supply: | DIN rail power supply |
Number of indoor stations: | 1 |
Number of outdoor stations: | 1 |
Can be connected to smartphone: | Yes |
Expandable to max. number of monitors: | 6 |
Wi-Fi frequency: | 2.4 GHz |
Expandable to max. number of outdoor stations: | 2 |
Wi-Fi standard: | 802.11 b/g/n |
Expandable to max. number of CCTV cameras: | 2 |
Operation door lock: | Yes |
Current supply of the electric strike: | from the external panel |
With automatic door opener: | Yes |
With day/night function: | Yes |
Monitor: | |
---|---|
Mounting method: | Surface mounted (plaster) |
Hands free: | Yes |
Screen diagonal: | 7 " |
Resolution of the monitor's screen: | 1024 x 600 |
Picture system: | PAL |
Property picture system: | Colour |
With memory function: | Yes |
SD card reader: | Yes |
Intercom: | Yes |
Number of ringtones: | 10 |
Loudness control: | Yes |
Monitor colour: | black |
Width: | 238 mm |
Height: | 144 mm |
Depth: | 20.5 mm |
External panel: | |
---|---|
Number of call buttons: | 1 |
Mounting method: | Surface mounted (plaster) |
Resolution of the camera: | 1920 x 1080 |
Opening angle camera (horizontal): | 110 ° |
Opening angle camera (vertical): | 58.5 ° |
Night lighting: | IR |
With digital door code: | Yes |
Card and proximity tags reader: | Yes |
Frequency of proximity cards and tags: | 13,56 MHz (Mifare) |
Degree of protection (IP): | IP44 |
Colour: | Black |
Width: | 48 mm |
Height: | 133 mm |
Depth: | 22 mm |
