  2. 140031-Adjustable flush mounted PIR motion sensor 360° protection rating IP20; detection range 360°, 6m; works with LEDs-ORN

140031-Adjustable flush mounted PIR motion sensor 360° protection rating IP20; detection range 360°, 6m; works with LEDs-ORN

https://electon.odoo.com/web/image/product.template/630/image_1920?unique=00d87fa

Passive infrared sensor For indoor usage Collaborates with LED lighting Regulation: lighting time (TIME) and the sensitivity of the light intensity (LUX) Installation in suspended ceilings.

16.94 € 16.94 EUR 16.94 €

21.17 €

SKU: ORNOR-CR-243
EAN: 5901752485105
Availability: Low Stock
Only 1.0 Units left in stock.

    This combination does not exist.

    Orno
    ORNO have been supplying innovative products under three main product lines to the market since 2001, and our new ideas are quickly converted into effective and proven solutions. That is why our products have gained recognition and a strong position on the European market.

    Technical specyfication

    General information:
    Max. load:800
    Max. load of the LED light source:200 W
    Degree of protection (IP):20
    Relay output:Yes
    Nominal voltage:230V~, 50Hz
    Presence detector:No
    Colour:white
    Installation:flush mounting
    Dimensions of the sensor - width (mm):80 mm
    Dimensions of the sensor - height (mm):80 mm
    Dimensions of the sensor - depth (mm):61.4 mm
    Detection angle:360°
    Dimensions of the mounting hole:60 mm
    Type of sensor:Infrared
    Detection range:Ø6m m
    Adjustable daylight sensor (LUX):Yes
    Daylight sensor adjustment range (LUX):<3—2000lux
    Adjustable time setting (TIME):Yes
    Lighting time adjustment range (TIME):min.: 10 sek. ± 3 sek., max.: 15min.±2min
    Adjustment of motion detection range (SENS):No
